KFT-09 · FlexiTrack Series
Inclined Modular
Gripped modular belt to elevate cartons and pouches.
A gripped modular belt lifting cartons and pouches from floor level to a machine infeed. Sprocket engagement keeps it tracking on the climb.
- Family Modular Belt
- Series FlexiTrack Series
- Type code KFT-09
- Configuration Inclined transfer
- Construction SS 304 / MS / Aluminium
Features
What is built into it
-
Modular, interlocking design enabling easy section replacement
-
Configurable for curves, inclines, and declines
-
Auto belt alignment with sprocket engagement
-
Smooth vertical transfer with space-saving design
-
Hygienic, durable construction requiring low maintenance
-
Suitable for multiple product types
-
Bi-directional operation with flexible motor positioning (right/left/center)
Specification
Standard ranges
An envelope, not a fixed configuration — every dimension is set on the GA drawing.
Inclined Modular — GA drawing, plan and elevation, key dimensions called out SVG or PDF · 1-colour line art · dimensioned Drawing pending
- Length
- 0.5-10 meters (customizable)
- Width
- 65-1200 mm
- Height
- 700-900 mm (customizable)
- Inclination
- 7.5, 15, 30, 45, 60 degrees (customizable)
- Material Construction
- SS 304 / MS / Aluminium
- Surface Finish
- SS Matt / Bead Blast / Painting & Powder Coating
- Belt Type
- Flat top, perforated, cleated, friction top, radius/curved
- Speed
- 5-30 m/min
- Motor Position
- Right / Left / Center
- Voltage
- 220V / 415V
- Drive Type
- Direct / Chain / Belt Drive
- Direction
- Bi-Directional
- Support
- Levelling Pads / Wheel
Applications
Where it runs
- Airports
- Assembly Lines
- Automobile
- Cosmetics
- E-commerce
- Electronics
- Food & Beverages
- Manufacturing
- Packaging
- Pharmaceuticals
- Warehousing
- Waste Management
- Product handling: bottles, blister packs, tablets/capsules, sheet metal parts, vaccine bottles, food grains, biscuits, and trays
