Features
What is built into it
-
No power source required — driven by gravity or manual push
-
Simple design architecture
-
Handles light to medium loads effectively
-
Modular and flexible layout options
-
Smooth, quiet operation
-
Space-saving design
-
Easy installation with low maintenance demands
Specification
Standard ranges
An envelope, not a fixed configuration — every dimension is set on the GA drawing.
Gravity Roller — GA drawing, plan and elevation, key dimensions called out SVG or PDF · 1-colour line art · dimensioned Drawing pending
- Length
- Customized
- Width
- 300-1500 mm
- Height
- 700-900 mm / Customized
- MOC
- SS 304 / MS
- Surface Finish
- SS Matt Finish / Bead Blast; MS Painting & Powder Coating
- Resting
- Levelling Pads / Wheel
- Drive
- Non-powered (gravity / manual push — no motor, voltage, or speed rating)
Applications
Where it runs
- Airports
- Assembly Lines
- Automobile
- Cosmetics
- E-commerce
- Electronics
- Food and Beverages
- Manufacturing
- Packaging
- Pharma
- Warehousing
- Waste Management
- Material transportation along production lines
- Moving boxed goods for storage or shipping
- Handling boxes, bottles, food grains, personal care items, sheet metal, vaccine bottles, blister packs, nuts, snacks, tablets, capsules, biscuits, and trays
