KFT-16 · Roller Series
Radius Power Roller
Powered curve for cartons and totes around corners.
A powered curve for cartons and totes, keeping the pack driven through the corner rather than coasting into the outside rail.
- Family Roller
- Series Roller Series
- Type code KFT-16
- Configuration Radius / directional change
- Construction SS 304 / MS
Features
What is built into it
-
Smooth curved product flow around corners
-
Powered rollers for consistent, steady movement
-
Durable, low-maintenance design
-
Variable speed control
-
Bi-directional operation
-
Configurable radius, width, and height (customizable)
-
Multiple roller types: Tapered / Sprocket Driven / Grooved
-
Selectable motor position: Right / Left / Center
-
Multiple drive options: Direct / Chain / Belt
Specification
Standard ranges
An envelope, not a fixed configuration — every dimension is set on the GA drawing.
Radius Power Roller — GA drawing, plan and elevation, key dimensions called out SVG or PDF · 1-colour line art · dimensioned Drawing pending
- Radius
- R500/R700/R1000/R1500 / Customized
- Width
- 300-1000 mm
- Height
- 700-900 mm / Customized
- MOC
- SS 304 / MS
- Surface Finish
- SS Matt Finish / Bead Blast; MS Painting & Powder Coating
- Speed
- 3-20 m/min
- Roller Type
- Tapered / Sprocket Driven / Grooved
- Roller Diameter
- 38-60 mm
- Motor Position
- Right / Left / Center
- Voltage
- 220 V / 415 V
- Drive Type
- Direct / Chain / Belt
Applications
Where it runs
- Boxes and packaged goods handling
- Bottle capping lines
- Food grains transport
- Personal care and cosmetic products
- Sheet metal parts handling
- Vaccine bottles and pharma packaging
- Blister packs, tablets, and capsules
- Biscuits and food products
- Tray transport in automated lines
- Airports and baggage handling
- Assembly lines and automobile manufacturing
- E-commerce and warehousing
- Electronics manufacturing
- Food & beverage processing
- Packaging and waste management
