KFT-07 · FlexiTrack Series
Modular Belt
Interlocking plastic belt for straight, curved and inclined runs.
Interlocking plastic belt segments that take straight, curved and inclined runs on the same line. Any section lifts out on its own.
- Family Modular Belt
- Series FlexiTrack Series
- Type code KFT-07
- Configuration Straight belt run
- Construction Stainless Steel 304, MS (mild steel), Aluminum
Features
What is built into it
-
Modular, interlocking design enabling straightforward repairs
-
Sections can be individually replaced or reconfigured
-
Automatic belt alignment through sprocket engagement
-
Easily adapted for straight runs, curves, and inclines/declines
-
Hygienic construction with minimal alignment issues
-
No-slippage belt characteristic
-
Lighter than metal or chain alternatives in many scenarios
Specification
Standard ranges
An envelope, not a fixed configuration — every dimension is set on the GA drawing.
Modular Belt — GA drawing, plan and elevation, key dimensions called out SVG or PDF · 1-colour line art · dimensioned Drawing pending
- Length
- 0.5-10 meters (customizable)
- Width
- 65-1200 mm
- Height
- 700-900 mm (customizable)
- Materials of construction
- Stainless Steel 304, MS (mild steel), Aluminum
- Belt types
- flat top, perforated, cleated, friction top, radius/curved
- Speed
- 5-30 m/min
- Motor positioning options
- Right, Left, Center
- Power supply
- Single/3-phase, 50 Hz
- Voltage
- 220V or 415V
Applications
Where it runs
- Moving medicines, bottles, and blister packs in cleanrooms
- Transporting boxes, trays, and pouches through production stages
- Handling warehouse inventory
- Airports
- Assembly Lines
- Automobile
- Cosmetics
- E-commerce
- Electronics
- Food and Beverages
- Manufacturing
- Packaging
- Pharma
- Warehousing
- Waste Management
