U-Type Modular
180° turn in a compact footprint.
A 180° turn that brings product back alongside its own infeed, folding a long process into half the floor length.
- Family Modular Belt
- Series FlexiTrack Series
- Type code KFT-04
- Configuration Radius / directional change
- Construction Stainless Steel 304 or Aluminum
What is built into it
-
U-shaped modular belt for smooth 180-degree product turns
-
Versatile application across multiple industries
-
Enhanced operational efficiency
-
Low maintenance requirements
-
Extended service life with durable modular plastic belt
-
Corrosion-resistant stainless steel or aluminum frame
-
Hygienic design suitable for regulated industries
-
Space optimization within compact production areas
-
Customizable configuration options
-
Simple assembly and quick belt replacement
-
High load-carrying capacity
-
Quiet and stable operation
-
Bi-directional operation capability
Standard ranges
An envelope, not a fixed configuration — every dimension is set on the GA drawing.
- Length
- 1-50 meters (customizable)
- Width
- 65 / 85 / 105 mm
- Height
- 700-900 mm (customizable)
- Material of Construction (MOC)
- Stainless Steel 304 or Aluminum
- Surface finish
- Hard anodized profiles with Munshell gray matt finish, or bead blasted
- Speed range
- 5-40 m/min (variable or fixed)
- Direction
- Bi-directional capable
- Drive type
- Direct, Chain, or Belt drive options
- Power supply
- Single-phase or 3-phase, 50 Hz
- Voltage
- 220V or 415V
- Motor position
- Right or left configuration
- Support options
- Foot rest or tripod mounting
Where it runs
- Food processing
- Packaging
- Pharmaceuticals
- Assembly operations / assembly lines
- Material handling
- Airports
- Automobile manufacturing
- Cosmetics
- E-commerce
- Electronics
- Food and beverages
- General manufacturing
- Warehousing
- Waste management
